Technical features NautilusTM tube loaded
aluminium dome tweeter
Kevlar® brand fibre cone bass / midrange
FlowportTM
Magnetic shielding
txt3 2-way vented-box system
Drive units 1x ø25mm (1 in) aluminium dome high-frequency
2x ø130mm (5
in) woven Kevlar® cone bass / midrange
Frequency range -6dB at 45Hz and
50kHz
Frequency response 55Hz - 22kHz ±3dB on reference axis
Dispersion
Within 2dB of reference response
Horizontal: over 20º arc
Vertical: over
60º arc
Sensitivity 85dB spl (2.83V, 1m)
Harmonic distortion 2nd and 3rd
harmonics (90dB, 1m)
<1% 100Hz - 22kHz
Nominal impedance 8Ω (minimum
4.3Ω)
Crossover frequency 4kHz
Recommended amplifier power 30W - 120W
into 8Ω on unclipped programme
Max. recommended cable impedance 0.1Ω
Dimensions
Height: 166.5mm (6.6 in)
Width: 480mm (18.9 in)
Depth: 275mm (10.8 in) including grille and terminals
Net weight 11.5kg
(25.5 lb
